J1 J1R2293V

Part Number J1R2293V
Marke J1

J1 J1R2293V

Part Number J1R2293V
Marke J1
Specifications
Type
ROTOR DISC
Location
Front Axle Rotor/Drum
Position
Left/Right
Centering Diameter
62
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Drum Ø:
168
Front/Rear
Front
Height
49.1
Hole Ø:
14.5
Num. of holes
5
Outter Ø
320
Pitch Circle Ø
114.3
Structure Material
G3000
Type
Vented
